960*960 P5 P6.67 P8 P10 Outdoor LED Display Screen with 2 Years Warranty and Full HD Video Wall
Ürün ayrıntıları:
| Menşe yeri: | Guangdong, Çin |
| Marka adı: | LEDKING or OEM & ODM |
| Model numarası: | FO-P5/6.67/8/10 |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 1 |
|---|---|
| Fiyat: | US$456-476 |
|
Detay Bilgi |
|||
| Piksel perdesi: | 5 mm, 6 mm, 6,67 mm | Piksel yoğunluğu: | 40000 nokta/m2, 27777 nokta/m2, 22477 nokta/m2 |
|---|---|---|---|
| Piksel yapılandırması: | 1R1G1B | Maksimum güç tüketimi: | 40W, 29W, 43W |
| Panel ağırlığı: | 0,45KG, 0,35KG, 0,45KG | Kabine boyutu: | 960mm*960mm*90mm, 576mm*576mm*90mm, 768mm*768mm*90mm |
| Kabine çözünürlüğü: | 192 nokta * 192 nokta, 96 nokta * 96 nokta, 128 nokta*128 nokta, 144 nokta*144 nokta | Hub bağlantısı: | HUB75-E |
| En iyi bakış açısı: | 170/120, 140/120 | Ekran güç kaynağı: | AC110V/220V - 5V60A |
| Maksimum güç kapasitesi: | 976W/m2, 1050W/m2, 1350W/m2 | Frekans yenileme: | 1920-3840HZ/S |
| Parlaklık: | 5000-5500 mcd/m2, 4000-5000 cd/m2 | Çalışma sıcaklığı: | -10°C~45°C |
| IP koruma indeksi: | IP65 | ||
| Vurgulamak: | 960*960 LED Video Wall,P5 P6.67 P8 P10 Outdoor LED Display Screen,2 Years Warranty LED Billboard |
||
Ürün Açıklaması
960×960 P5 P6.67 P8 P10 LED Billboard Outdoor Advertising Full HD Video Panel LED Wall Display
Module Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Panel Dimension | 320mm(W) × 160mm(H) | 192mm(W) × 192mm(H) | 320mm(W) × 160mm(H) |
| Pixel pitch | 5mm | 6mm | 6.67mm |
| Pixel Density | 40000 dot/m² | 27777 dot/m² | 22477 dot/m² |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD1921 | SMD3535 | SMD3535 |
| Pixel resolution | 64 dot × 32 dot | 32 dot × 32 dot | 48 dot × 48 dot |
| Max power consumption | 40W | 29W | 43W |
| Panel weight | 0.45KG | 0.35KG | 0.45KG |
Cabinet Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Cabinet size | 960mm×960mm×90mm | 576mm×576mm×90mm, 768mm×768mm×90mm | 960mm×960mm×90mm |
| Cabinet Resolution | 192 dot × 192 dot | 96 dot × 96 dot, 128dot×128dot | 144dot×144dot |
| Quantity of panel | 18pcs | 9pcs, 16pcs | 18pcs |
| Hub connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Diecasting aluminum cabinet | Diecasting aluminum cabinet | Diecasting aluminum cabinet |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best viewing angle | 170/120 | 140/120 | 140/120 |
| Screen power supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max power capacity | 976W/m² | 1050W/m² | 1350W/m² |
| Average power | 488W/m² | 525 W/m² | 675W/m² |
Technical Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 / 2153 |
| Scan Rate | 1/8S | 1/8S | 1/6S |
| Refresh frequency | 1920-3840 HZ/S | 1920-3840 HZ/S | 1920-3840 HZ/S |
| Display color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 5000-5500 mcd/m² | 4000-5000 cd/m² | 4000-5000 cd/m² |
| Life span | 100000 Hours | 100000 Hours | 100000 Hours |
| Control distance | < 100M | < 100M | < 100M |
| Best viewing distance | 5-40M | 6-40M | 6-40M |
| Operating temperature | -10°C ~ 45°C | -10°C ~ 45°C | -10°C ~ 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP protective index | IP65 | IP65 | IP65 |
